钢球：Gcr15轴承钢，热处理，HRC58-64°，并经过精磨，表面镀硬铬处理
外圈：碳钢
COM..T/HCOMT..:PTFE复合物或者PTFE编织物
滑动摩擦副：钢/PTFE复合物
外圈：碳钢
COM..T/HCOMT..:PTFE复合物或者PTFE编织物
滑动摩擦副：钢/PTFE复合物
| 轴承型号 | 尺寸 IN INCHES | |||||||||
PTFE Lined | B +.065 -.013 | D +.000 -.018 | T ±.13 | w ±.12 | 0 Flat Dia. Ref. | M 倒角 | 钢球直径 | 调心角度 | 极限静态 径向载荷 (Newtons) | 估重 (g） |
| MCOM5T | 5 | 16 | 6.00 | 8 | 7.68 | 0.5 | 11.10 | 12.5 | 27,555 | 9 |
| MCOM6T | 6 | 18 | 6.75 | 9 | 8.93 | 0.5 | 12.70 | 12.5 | 35,459 | 13 |
| MCOM8T | 8 | 22 | 9.00 | 12 | 10.35 | 0.8 | 15.88 | 14.0 | 59,121 | 24 |
| MCOMIOT | 10 | 26 | 10.50 | 14 | 12.88 | 0.8 | 19.05 | 13.5 | 82,744 | 40 |
| MCOM12T | 12 | 30 | 12.00 | 16 | 15.39 | 0.8 | 22.23 | 13.0 | 112,829 | 80 |
| MCOM14T | 14 | 34 | 13.50 | 19 | 16.86 | 1.0 | 25.40 | 16.0 | 141,845 | 110 |
| MCOM16T | 16 | 38 | 15.00 | 21 | 19.34 | 1.0 | 28.58 | 15.0 | 177,343 | 130 |
| MCOM18T | 18 | 42 | 16.50 | 23 | 21.89 | 1.0 | 31.75 | 15.0 | 216,714 | 170 |
| MCOM20T | 20 | 46 | 18.00 | 25 | 24.35 | 1.0 | 34.93 | 14.5 | 260,086 | 230 |
| MCOM22T | 22 | 50 | 20.00 | 28 | 25.84 | 1.5 | 38.10 | 15.0 | 315.216 | 280 |
| MCOM25T | 25 | 56 | 22.00 | 31 | 29.60 | 1.5 | 42.86 | 15.0 | 390,056 | 390 |
| MCOM30T | 30 | 66 | 25.00 | 37 | 34.81 | 1.5 | 50.80 | 17.0 | 525,360 | 610 |
